TOA 2300 series fiber amplifier is single wavelength gain fixed fiber amplifier of telecommunication level.

　　The core components of the amplifier adopt the world's top brand pump laser and erbium-doped fiber. The optimized optical design and production process ensure the best optical performance. The perfect electronic controlled modes of APC (automatic power control), ACC (automatic current control) and ATC (automatic temperature control) circuits are adopted to ensure high stability and reliability of the output power, at the same time, it also guarantees excellent optical path index.

1.It adopts the world's top brand pump laser and erbium-doped fiber.

2. Perfect APC, ACC and ATC optical circuit design ensure low noise, high output and high reliability of the device in the whole operating band (1529.16~1563.86nm).

3.It has the function of automatic protection of low input or no input. When the input optical  power is lower than the set value, the laser will automatically shut down to protect the operating safety of the laser.

4.Fully integrated electronic transient Technology

5.Advanced low power consumption control technology

6.Operating Mode: Fixed Gain

 7.Output power is suppressed by transient suppress technology.

8. Output adjustable, adjustment range 0~-4dBm

9. Max output reaches 23dBm

10.Fully automatic case temperature control and intelligent fans, the fans start to work when the case temperature reaches 35 ℃.

11.Built-in dual power supply, automatically switched and hot plug in/out supported.

12.The operating parameters of the whole machine are controlled by microprocessor,    and the LCD status display on the front panel has many functions such as laser status  monitoring, parameter display, fault alarm, network management, etc.; once the operating parameters of the laser deviate from the allowed range set by the software, the system will alarm promptly.

9.Standard RJ45 interface is provided, supporting SNMP and web remote network management.
