TOS2000TRW series RF switch module is featured in short switching time and low loss, which is mainly used in ring network or redundant standby network. When the main line fails or is lower than the set threshold value, it will automatically switch to the standby line. When the main line returns to normal, it will automatically return to the main line. When device is in the mode of manual forced switching , it can switch to the main line or the standby line as you like.

　　The product has the characteristics of small size and compact structure, and can be used with TOS2000TEL power supply and TOS2000TJK optical platform to form an optical transmission system with excellent performance.

1.RF switch is featured in short switching time, low loss, with automatic switching and forced manual switching function.

2. Large RF switching dynamic range.

3. High isolation.

4.The built-in microprocessor monitors all the operating status parameters of the module and transmits them to the platform through the bus. The platform can monitor and display its operating status through LCD screen. The intelligent function of the platform provides a good internal operating environment for the module, so that the excellence of the module can be brought into play, with high reliability and stability.
